Antelope Audio Atlas i8 2x8 inch Isobaric 3-way Powered Studio Monitor
Tax included.
The Atlas i8 is a high-end studio monitor that synergizes Antelope Audio’s state-of-the-art clock and interface technologies with meticulous acoustical engineering to deliver unparalleled sound accuracy in any studio environment.
Featuring an isobaric configuration with two 8-inch woofers, a coaxial mid and high-frequency driver, and a custom Class-D 400W amplifier, the Atlas i8 delivers precise audio reproduction between 35 and 20 000 Hz with a maximum SPL of 117dB.
A custom digital processing system with FPGA chips enhances the performance, achieving a neutral frequency response and linear phase. The result is an accurate, pinpoint sound and a fatigue-free listening experience.The DSP also unlocks a handful of features that improve everyday studio life.
Key Features
- Isobaric design (2x8" woofers)
- Digital calibration with FIR and IIR filters
- Linear phase frequency response
- Custom class-D amplifier
- 64-bit Acoustically Focused Clocking
- High-quality AD/DA converters
- Coaxial driver for mid & high frequencies
- Color display with advanced settings menu
- Parametric EQ
- Remote software control panel
- Delay offset
- Preset management
- 18mm cabinet with extra reinforcement
- Optional mounting plate
- Vertical and horizontal positioning
- Hand-built in EU
Technical specifications
- Frequency range: 35 - 20 000 Hz
- Max SPL: 117dB at 1 m
- Amp wattage: 400W (200W low + 100W mid + 100W high)
- Input connectors: Analog XLR/TRS; Digital AES/EBU
- Output connectors: Digital AES/EBU
- Driver sizes: LF: 2x8" isobaric, MF: 5,5", HF: 1,5" coaxial
- Speaker configuration: Three-way
- Active or passive: Active
- AD/DA converter: 24-bit/ 192 kHz
- Equalization: Digital parametric
- Enclosure Type: Front ported
- Monitor application: Near-field / Mid-field
- Dimensions: W 292 mm, D 387 mm, H 500 mm
- Weight: 24 kg
